Usage

Insulation resistance tester is used to test the characteristics of insulation resistance value of insulating appliances and insulating materials under specified medium environment and specified voltage.

Feature

n Use the micro-computer to control, menu operation, LCD display, stable performance, smart instrument.

n Strong anti-interference capability.

n 7 voltage output taps: 50V, 100V, 250V, 500V, 1.0kV, 2.5kV, 5.0kV.

n Can adjust the output high voltage continuously from zero.

n Automatically measure R15, R60 and R600; calculate the absorption rate and polarization index and display the leakage current and absorbed capacitance.

n Strong load capacity and the short-circuit current is about 5mA.

n Measuring range 0-10TΩ and automatic range switch.

n Display the test time at any time and the buzzer sounds every 15s.

n If the test object is found to be live before test, live voltage and related prompts will be shown.

n Be allowed to set the test time

n Automatically measure the ambient temperature, humidity, test date and time.

n Can store 60 days of test results.

n With RS232 interface

n If no operations within 5 minutes, the device prompts you to shut down the computer.

n Having all-round protection functions and high reliability.

Technical parameters
