Current Transformer Burden UCL2203
    Publish time 2021-06-18 17:01
Current Transformer Burden UCL2203

Usage

The Current Transformer Burden is applicable to current transformer accuracy testing as secondary load of test object CT, its series connection to the secondary winding of test object CT.



Technical Specification(It is for general reference,we can customize it as per user’s request)

Rated Current:

5A; 1A

Power Factor

and Rated Capacity:

When rated current is 5A:

COSФ=0.8: 2.5/3.75/5/6.25/7.5/10/12.5/15/20/25/30/40/50/60VA

COSФ=1.0: 2.5/3.75/5/6.25/7.5/10VA

When rated current is 1A:

COSФ=0.8: 0.1/0.15/0.2/0.25/0.3/0.4/0.5/0.6/0.8/1.0/1.2/1.6/2.0/2.4

2.5/3.75/5/6.25/7.5/10/12.5/15/20/25/30/40/50/60VA

COSФ=1.0: 0.1/0.15/0.2/0.25/0.3/0.4/2.5/3.75/5/6.25/7.5/10VA

Accuracy Class:

±3%

OperationFrequency:

50Hz

Operating Range:

(5%-120%) In

Test CableResistance:

0.06Ω

Withstand Voltage:

2000V 1min

Operating Condition:

Temperature: 10 oC ～ +40 oC

Relative Humidity (RH): up to 85% (max 90%)
